| 1 |
Axle, Rr. Wheel (42301-K04-930)
|
E
|
€27.07
|
|
| 2 |
Body Comp., Frame (50100-K53-D00)
|
E
|
€1,457.05
|
|
| 3 |
Stay Comp., Fr. Cover (50310-K53-D00)
|
E
|
€75.55
|
|
| 4 |
Bracket Sub Assy. B, Engi (50340-K53-D00)
|
E
|
€174.00
|
|
| 5 |
Collar B, Engine Hanger (50352-KTW-900)
|
E
|
€23.26
|
|
| 6 |
Rubber B, Stopper (50354-428-000)
|
E
|
€3.28
|
|
| 7 |
Bracket Assy. A, Engine H (50360-KTW-B00)
|
E
|
€97.88
|
|
| 8 |
Rod Comp., Swing (50380-K04-930)
|
E
|
€259.83
|
|
| 9 |
Dust Seal, 31X38.5X7 (Nok (52144-GF5-003)
|
E
|
€10.81
|
|
| 10 |
Rubber, Headlight Case (61304-415-000)
|
E
|
€3.60
|
|
| 11 |
Guard, Harness (64312-K53-D00)
|
E
|
€7.88
|
|
| 12 |
Stay, Control Unit (64313-K53-D00)
|
E
|
€4.96
|
|
| 13 |
Bolt, Flange, 12X355 (90101-K53-D00)
|
E
|
€23.62
|
|
| 14 |
Bolt, Flange, 12X260 (90102-K53-D00)
|
E
|
€24.65
|
|
| 15 |
Nut, Spring, 4Mm (90302-KWW-A00)
|
E
|
€2.35
|
|
| 16 |
Nut, U, Flange. 10Mm (90304-GBL-003)
|
E
|
€4.21
|
|
| 17 |
Nut, Flange, 12Mm (Fuse R (90306-KF0-003)
|
E
|
€4.78
|
|
| 18 |
Clamp, Harness (90652-HC4-003)
|
E
|
€4.28
|
|
| 19 |
Bearing, Swingarm Pivot ( (91071-KS6-004)
|
E
|
€14.10
|
|
| 20 |
Bolt-Washer, 6X12 (93404-0601200)
|
E
|
€1.14
|
|
| 21 |
Screw, Tapping, 4X10 (93903-34280)
|
E
|
€0.68
|
|
| 22 |
Nut, Flange, 8Mm (94050-08000)
|
E
|
€1.50
|
|
| 23 |
Bolt, Flange, 8X38 (95801-0803800)
|
E
|
€2.42
|
|
| 24 |
Bolt, Flange, 10X60 (95801-1006000)
|
E
|
€1.82
|
|
| 25 |
Bolt, Flange, 10X70 (95801-1007000)
|
E
|
€2.35
|
|
| 26 |
Rivet, Plate (90841-KM1-670)
|
E
|
€1.71
|
|
